Technical Specifications
- All-in-one Machine
- Discrete / Random Access System
- Start Sample Priority Function
- User-Friendly Interface
- Internal Thermal Printer – Direct Report Printing
- 81 Reaction Cuvettes
- 24 + 5 Sample Positions (Tube @ 12×100)
- 1 Calibration Position / 1 QC Position / 1 ST Position
- 54 Reagent Positions
- 27 Reagent Bottles – 8 ml Volume
- 27 Reagent Bottles – 24 ml Volume
- LED Light Source with:
- 8-Channel Transmissometry
- 1-Channel Scattering (Rear Spectrophotometry)
- Liquid Level Detection & Collision Protection
- High-Pressure Water Flush for Probe Washing
- Carry-over < 0.1%
| Automation | Fully Automatic |
|---|---|
| Brand | JITM C GENES PVT LTD |
| Assays | Clinical Chemistry |
| Model Name | CS 120 |
| Reaction Cuvette | Reusable Cuvette |
| Storage Capacity | 50,000 Tests |
| Test Method | Colorimetry |
| Usage / Application | Clinical Pathology |
| Water Consumption | 2 L / Hour |
| Wavelength | 8 Wavelengths |
| Throughput | 120 Tests / Hour |
| Number of Reagent Positions | 56 |
| Photometric Range | 0 – 3 Abs |
