• Principles:

  WBC: Flow Cytometry (FCM) + Laser Light Scatter + Cytochemical Staining Method
  RBC / PLT: Electrical Impedance Method
  HGB: Non-Cyanide Photometric Method
• Parameters:
  25 Report Parameters:
  WBC, Bas#, Bas%, Neu#, Neu%, Eos#, Eos%, Lym#, Lym%, Mon#, Mon%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, P-LCC
• Research Parameters: ALY#, ALY%, LIC#, LIC%
• Histograms: 2 (RBC, PLT)
• Scattergrams: 4 (WBC Differential)
• Data Storage Capacity: Up to 50,000 Results with Scattergrams and Histograms
• Communication: LAN Port Supports HL7 Protocol
• Interface:
  4 USB Ports, 1 Ethernet Port
  Support for Uni-directional LIS
  Supports Printer, Keyboard, Mouse, Barcode Scanner
• Sample Volume:
  Whole Blood: 20μL
  Capillary Whole Blood: 20μL
  Pre-diluted Mode: 20μL
• Printout:
  External Laser / Inkjet / Thermal Printer
  Various & User-defined Print Formats
• Operating Environment:
  Temperature: 10–30°C
  Humidity: ≤70%
• Machine Dimension & Weight:
  325mm × 465mm × 470mm
  Weight: 30 Kg
• Package Dimension & Weight:
  630mm × 490mm × 630mm
  Weight: 35 Kg
• Display: 10.4" Color Touch Screen
• Throughput: Up to 60 Samples per Hour

Performance
