Technical Specifications
-
Parameters:
WBC, LYM#, MID#, GRAN#, LYM%, MID%, GRAN%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW-SD, PDW-CV, PCT, P-LCR, P-LCC -
Principles of Operation:
WBC / RBC / PLT: Electrical Impedance
HGB: Photoelectric Colorimetry - Aspiration Volume: Whole Blood 8.5 μL, Pre-diluted 20 μL
- Aperture Diameter: WBC 100 μm, RBC/PLT 68 μm
- Throughput: 72 Samples per Hour
- Data Storage: Up to 100,000 Sample Results with Histograms
- Alarms: Error Messages
- Display: 10.4" Color LCD, 800 × 600 Resolution, Touch Screen
- Controls / Calibration: L-J, X, X-R, X-B Control Modes, Manual & Auto-Calibration
-
Input / Output:
RS232, 6 USB Ports (Mouse, Keyboard, HP Printer, Barcode Reader, Flash Disk), Internal 57mm Thermal Printer - Power Supply: AC 100–240V, 50/60Hz, 130VA
- Dimensions & Weight: 415mm (L) × 305mm (W) × 395mm (H), ~18 Kg
